ENGINE MANAGEMENT SYSTEM
- 340 -
EMS FAULT DIAGNOSIS
EME Fault Diagnosis
When fault comes up, the odometer's clock will turn into a number， which is a fault code, find out
the cause with this numbe;press clock button,then it will turn back to clock mode, and five second
later,the fault code will show again.
Fault code list
System or
Component
DTC
Number
DTC Description Related Calibration
Manifold Absolute
Pressure Sensor
(MAP)
0107 MAP Circuit Low Voltage or Open KsDGDM_MAP_ShortLow
0108 MAP Circuit High Voltage KsDGDM_MAP_ShortHigh
Intake Air
Temperature Sensor
(IAT)
0112 IAT Circuit Low Voltage KsDGDM_IAT_ShortLow
0113 IAT Circuit High Voltage or Open KsDGDM_IAT_ShortHigh
Coolant/Oil Sensor
0117
Coolant/Oil Temperature Sensor
Circuit Low Voltage
KsDGDM_CoolantShortLow
0118
Coolant/Oil Temperature Sensor
Circuit High Voltage or Open
KsDGDM_CoolantShortHigh
Throttle Position
Sensor (TPS)
0122 TPS Circuit Low Voltage or Open KsDGDM_TPS_ShortLow
0123 TPS Circuit High Voltage KsDGDM_TPS_ShortHigh
Oxygen Sensor
0131 O2S 1 Circuit Low Voltage KsDGDM_O2_1_ShortLow
0132 O2S 1 Circuit High Voltage KsDGDM_O2_1_ShortHigh
Oxygen Sensor
Heater
0031 O2S Heater Circuit High Voltage KsDGDM_O2_HeaterShortHigh
0032 O2S Heater Circuit Low Voltage KsDGDM_O2_HeaterShortLow
Fuel Injector
0201 Injector 1 Circuit Malfunction KsDGDM_INJ_CYL_A_Fault
0202 Injector 2 Circuit Malfunction KsDGDM_INJ_CYL_B_Fault
Fuel Pump Relay
(FPR)
0230
FPR Coil Circuit Low Voltage or
Open
KsDGDM_FPP_CircuitShortLow
0232 FPR Coil Circuit High Voltage KsDGDM_FPP_CircuitShortHigh
Crankshaft
Position
0336 CKP Sensor Noisy Signal KsDGDM_CrankNoisySignal
Sensor (CKP)
0337 CKP Sensor No Signal KsDGDM_CrankNoSignal
Ignition Coil
0351
Cylinder 1 Ignition Coil
Malfunction
KsDGDM_EST_A_Fault
0352
Cylinder 2 Ignition Coil
Malfunction
KsDGDM_EST_B_Fault
Idle Control
System
0505 Idle Speed Control Error KsDGDM_IdleControl
