CHASSIS

- 223-

PARKING BRAKE CALIPER AND BRAKE PADS

No. Part Name Qty Remarks

Removing the parking brake caliper

and brake pads

parking skid plate

Brake fluid

1 Parking brake switch coupler 1

2 Spring 1

3 Parking brake cable 1

Parking brake lever assembly mounting

Bolt

5 Parking brake lever assembly 1

6 Union bolt 1

7 Copper washer 2

8 Brake hose 1

9 Brake caliper mounting bolt 2

10 Brake caliper mounting bolt 2
