CHASSIS

- 286-

OIL SYSTEM

FUEL TANK

No. Part Name Qty Remarks

Removing the fuel tank

Fuel Tank Assy.

Oil Pump Plug

Oil pump gland 1

Breather pipe,fuel tank

Fuel outlet Plug

Spring Clamp E

Pressure Clamp A

Triplet Joint Fuel Pipe

High Pressure Fuel PipeⅠ
