CHASSIS

- 261-

SUSPENSION

Front Suspension and arm

No. Part Name Qty Remarks

Removing front suspension and arm

1 Left front upper swing arm 1

Joint A，suspension

3 Circlip D0=30 4

4 Right front upper swing arm 1

5 Left front lower swing arm 1

6 Right front lower swing arm 1

7 Middle rubber tube, swing arm 8

8 Hexagon flange bolt M10×1.25×70 8
