CHASSIS

- 275-

RADIATOR 2

No. Part Name Qty Remarks

Removing the radiator 2

1 Oil cooler cover 1

2 Weding Oil Cooler Assy 1

3 lubricating oil cooler 1

4 Locking Hoop For Screw A 12

rubber fuel line

Ⅰ

Cross Large Plate Head Screw M6

fixing pipe clamp(M type)

Hexagon Flange Nut M6

Metal Oil Pipe

Ⅲ

Pressure proof Rubber Oil Pipe

Ⅲ
