Dual Lift Arm Auto-Leveler

1. Press selector knob (2) while displaying basic screen (1)

to display Main Menu screen (3).

2. Rotate selector knob (2) to highlight Dual Lift Arm Auto-

Leveler (4).

3. Press selector knob (2) to display Dual Lift Arm Auto-

Leveler screen (5).

4. Rotate selector knob (2) to select Height Kickout (6) or

Lower Kickout (7).

5. Press selector knob (2).
