MAINTENANCE
7-111
N. Miscellaneous
Check Bucket Teeth
--- every 10 hours (daily)
Check bucket teeth for wear and looseness, and replace them
as needed.
Replace
d
WARNING: Guard against injury from flying pieces
of metal. Wear goggles or safety glasses, hard hat and
face shield.
1. Raise the bucket to an appropriate height with the
bucket bottom parallel to the ground.
Insert hard wood support blocks under the bucket to
support it.
Stop the engine.
2. Remove lock pin (1) and remove bucket teeth (2) from
adapter nose (4) using tool (3).
3. Install new teeth (2) onto adapter (4).
4. Install lock pin (1) with the guide rib (5) facing back.
115Z7-7-95-1
95ZV0014
95ZV0015
95ZV0016
