MOVING THE MACHINE
4-2
Starting to Move
d
WARNING: Start to move the machine only after
checking that no personnel and/or obstacles are
present around the machine.
Never turn ride control switch (4) (option) to ON
position when traveling the machine or raising
the bucket. Before turning the ride control switch
(4) ON, stop the machine and confirm that no
one is around the bucket. Avoid turning ride
control switch (4) to ON position while moving the
machine. Failure to do so may automatically move
the lift arm up or down.
Refer to page 1-109 for detailed information of ride control
switch (4).
1. Check that none of the warning indicators except
parking brake indicator (1) on the monitor panel are
ON when engine is running.
2. Set the front attachment in the operating position by
operating control levers (2) (3).
95Z7B-3-9-1
1
4
Multi-Function Joystick Type
MNEC-01-043
2, 3
Fingertip Control Type
4
2, 3
115Z7B-1-9-4
Position
A: 545 mm (21.5 in)
115Z7B-4-1-1
A
To Next Page
