OPERATOR'S STATION
1-139
Inspection/Maintenance Access Covers
d
CAUTION:
 Always close side covers (1) and top cover (3)
when moving and/or operating machine.
 Do not keep the side cover open on a slope or
when a strong wind is blowing. Failure to do so
may be dangerous because the side cover may
unexpectedly move or close.
 Take care not to pinch fingers when opening/
closing side cover (1) and/or top cover (3).
 When fully opening side cover (1), lock lever (5)
automatically slides and is positioned in the lock
position. Make sure that lock bar (5) is firmly
positioned to lock the cover.
To release the lock, pull wire (4) and release the
end of lock bar (5) from the lock position.
 Never attempt to stand on fender (2) if side cover
(1) is provided with fender (2).
115Z7B-1-142-2
3
1
5
4
115Z7B-1-142-1
115Z7B-1-142-3
1
2
