OPERATOR'S STATION
1-137
Articulation Stopper (Lock Bar)
d
WARNING:
Before servicing or transporting the machine, be
sure to engage lock bar (1).
Before driving the machine, be sure to disengage
the lock bar (1) from the front chassis and fasten
the lock bar to the rear chassis with lock bolt (2).
Articulation lock bar (1) locks the front and rear chassis to
prevent articulation between the front and rear chassis
when servicing or transporting the machine.
Refer to page S-38 for details.
"LOCKED" position
"STORED" position
MNHE-07-005
MNHE-07-004
1
2
1
