Hitachi ZW 550-6 User Manual

MAINTENANCE
7-4
Layout
1- Bucket Teeth
2- Bucket
3- Bucket Cylinder Rod Pin
4- Bucket Cylinder
5- Front Combination Lamp
6- Hydraulic Oil Tank
7- Air Cleaner
8- Aftertreatment Device
9- Radiator, Oil Cooler, and Other Cooling System
10- Rear Combination Lamp
11- Radiator Fan
12- Battery
13- Fuel Tank
14- Rear Axle
15- Engine
16- Third (Rear) Propeller Shaft
17- Transmission
18- Second (Front and Center) Propeller Shaft
19- Steering Cylinder
20- Front Axle
21- Lift Arm (Boom) Cylinder
22- Lift Arm (Boom) Cylinder Rod Pin
23- Bell Crank (Lever) Pin
24- Bucket Link Pin
25- Bucket Hinge Pin
26- First (Main) Propeller Shaft
27- Torque Converter
28- Cab
29- ROPS (Roll Over Protective Structure)
30- DEF Tank
31- DEF Supply Module
115Z7B-1-2-1
2
5
9
7
8
6
1
24
23
3
4
17
16
14
27
12
19
18
21
20
22
25
15
13
31
11
30
10
26
29
28

Hitachi ZW 550-6 Specifications

General

Brand	Hitachi
Model	ZW 550-6
Category	Front End Loaders
Language	English
