MAINTENANCE
7-90
Check Parking Brake Gear Oil Level
--- every 250 hours
1. Park the machine following the same procedures as
described on page 7-6 for preparation of inspection/
maintenance work.
2. Install articulation stopper (lock bar) (1) to the front
and rear of the chassis by following the procedures
described on page 7-8.
3. Clean the vicinity of oil plugs (2, 3).
4. Remove oil level plugs (2, 3) for oil level check.
5. Fill the oil from plug (2) until oil comes out of plug (3).
6. Install and tighten plugs (2, 3).
115Z7-7-91-2
MNHE-07-005
1
3
2
To Next Page
