OPERATOR'S STATION
1-55
Rear View Camera Monitor
IMPORTANT: The image displayed on the rear view
monitor is meant only as an aid. Actual position
and distance of people and objects in the rear view
monitor will be different from the actual view.
When operating the machine, pay thorough attention
to the surroundings with use of mirrors and windows.
1. Press selector knob (2) while displaying Basic Screen (1)
to display Main Menu screen (3).
2. Rotate selector knob (2) to highlight Setting Menu (4).
3. Press selector knob (2) to display Setting Menu screen
(5).
4. Rotate selector knob (2) to highlight Rear View Camera
Monitor (6).
MNEC-01-006
2
5
3
4
6
1
MNHG-01-140EN
MNHG-01-160EN
MNHG-01-103EN
MNHG-01-104EN
(Rear View Camera Sight)
Operating Rear View Monitor
To Next Page
