Hitachi ZW 550-6 User Manual

COMPONENTS NAME
1-1
Components Name
1- Bucket Teeth
2- Bucket
3- Bell Crank (Lever)
4- Bucket Cylinder
5- Front Combination Light
(Headlight/Turn Signal/Clearance Light/Hazard Light)
6- Outside Rear View Mirror
7- Front Work Light
8- ROPS (Over the Cab)
9- Rear Fender
10- Front Fender
11- Lift Arm Cylinder
12- Lift Arm
13- Battery (Two on the left side)
14- Fuel Filler Port
15- Rear Work Light
16- Aftertreatment Device (Inside the cover)
17- Exhaust Pipe
18- Hydraulic Oil Tank
19- Articulation Lock Bar
20- Rear Combination Light
(Turn Signal/Hazard Light/Tail Light/Brake Light/Backup
Light)
21- Counterweight
22- Towing Pin
23- Cooling Unit
24- DEF Tank
115Z7B-1-1-1
115Z7B-1-1-2
1
9
14
13
8
7
6
5
4
3
2
12
11
10
19
18
23
22 21 24
15
20
16
17
