17. DISCHARGE GUARD / GRASS BAG
17.1 Discharge guard
a. Disassembly / Reassembly
[1] STOPPER WASHER (2)
[2] DISCHARGE GUARD SHAFT
[3] GUARD RETURN SPRING
[4] DISCHARGE GUARD
- 118 -
HRA536 - HRD535 - HRD536
[1]
[2]
[3]
[4
]
- DISCHARGE GUARD / GRASS BAG
