Honeywell CNI2 User Manual

CNI2
O
perating and Installation
Guide
157
ELECTRICAL
–
DIGITAL INPUTS
Number of
inputs
Six
in
puts
are avail
able if not being used as outputs
.
Input Configuration
Form
-
A or Form
-
B (independently configurable). Two inputs can be paired for Form
-
C
o
peration.
Input rate (sampling mode)
10 Hz maximum
Minimum input
pulse
width (sampling mode)
25 mS
.
Sample rate (sampling mode)
1
–
50 samples per second (applies to all 6 inputs).
Sample rate is user
-
selectable. A value of
0 selects
edge
-
detection mode.
Debounce Count
(sampling mode)
Number of samples needed to declare an input valid.
This is use
r
-
selectable and each input is
independently
configurable. For instance if the sample rate is 4 samples per second, and the
debounce value is set to 20, then the signal must be in the same state for 20 consecutive
s
amples to be declared
valid, which woul
d be for a period of 5 seconds. Debounce values are
ignored in edge
-
detection mode.
Input rate
(e
dge
-
detection mode)
TBD Hz maximum
Minimum pulse width (e
dge
-
detection mode)
TBD mS.
Wetting current per
input
33 μA nominal.
Wetting voltage
+3.3V nominal
.
Input
resistance
100Ω
J7, J9, J11, J12 Connector Type
2
-
Pin MTA
with
2.54 mm (0.1”) spacing. Recommended mating connector is AMP 641190
-
2.
Recommended Input
Cable
Alpha 6300/4, Belden 9534, or equivalent having less than 100pF/ft capacitance. This
cable
type is 24awg, shielded, and has a PVC jacket.
Terminate only one end of the cable shield to
signal common or ground.
Maximum cable length run should not exceed 1000 feet. Other
cable types or gauges can be also be used as long as careful considera
tion is given to suitable
wiring practices and performance.
