Honeywell CNI2 User Manual

CNI2
O
perating and Installation
Guide
158
ELECTRICAL
–
SERIAL PORT (TB2)
Number of input lines
Two (
2
),
RXD
receive data and DTR handshake
Input levels
DTR:

15V max.
RXD:

15V max (JP3
-
3 in B
-
C position) or +3.3V/0V max
JP3
-
3 in A
-
B
position)
Number of output l
ines
Three (
3
) with EIA / RS
-
232 levels:
TXD transmit data, DCD and
DSR handshakes
Three (
3
)
with non
-
inverted logic levels
:
TXD_B transmit data
DCD_B and DSR_B handshakes
Output levels

5.5V max for EIA / RS
-
232 signals.
+3
.3V / 0V max for logic
-
level
signals.
Bit rate
300 to
115200
(user
-
selectable)
TB2 Connector Type (RXD, TXD, GND)
Socket:
RIA Connect Type 343,
3
-
position, Part number
P/N
313431
-
03
Plug
-
in Terminal Block:
RIA Connect
Type 339
,
3
-
position, Part number
P
/N
313391
-
0
3
TB2 Connector Type (all other signals)
Socket:
RIA Connect Type 343,
7
-
position, Part number
P/N
313431
-
07
Plug
-
in Terminal Block:
RIA Connect
Type 339
,
7
-
position, Part number
P/N
313391
-
0
7
