Honeywell Fusion4 MSC-L User Manual

System Description - Output Functions
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 3 - 55
3.9.3.2 Characteristics
3.9.4 Digital Output Electromechanical Relay (DC)
3.9.4.1 Functional Description
The Digital Output Electromechanical Relay (DO EMR DC) allows the
controller to switch DC signals to control alarms and other loads.
The two output terminals are “volt-free” contacts and require an external
power supply to drive a load.
The relay output contacts are effectively Single Pole Single Throw
(SPST) and are configurable through a jumper
1
to be either Normally
Open (NO) or Normally Closed (NC).
FIGURE 3-33 illustrates the simplified block diagram of the DO EMR
DC connections.
Item Minimum Typical Maximum Unit
Isolation - - 500 V
AC
V
LOOP
23.0 24.0 36.0 V
DC
Nominal loop current range 4 - 20 mA
Loop current control range 3 - 21 mA
Accuracy (without external
receiver)
- - ±1.0 %
Update time - - 250 ms
Load resistance 0 - 750 
1. For physical location(s),
see CHAPTER 4 - Installation.
