Model 2701 User’s Manual Status Structure 11-5
Programming and reading registers
Programming enable registers
The only registers that can be programmed by the user are the enable registers. All other
registers in the status structure are read-only registers. The following explains how to
ascertain the parameter values for the various commands used to program enable registers.
The actual commands are covered later in this section.
A command to program an event enable register is sent with a parameter value that
determines the desired state (0 or 1) of each bit in the appropriate register. An enable
register can be programmed using any of the following data formats for the parameter
value: binary, decimal, hexadecimal, or octal.
The bit positions of the register (Figure 11-2) indicate the binary parameter value. For
example, if you wish to sets bits B4, B3, and B1, the binary value would be 11010 (where
B4=1, B3=1, B1=1, and all other bits are 0). When you use one of the other formats,
convert the binary number to its decimal, hexadecimal, or octal equivalent:
Binary 11010 = Decimal 26 = Hexadecimal 1A = Octal 32
Note that Figure 11-2 includes the decimal weight for each register bit. To set bits B4, B3,
and B1, the decimal parameter value would be the sum of the decimal weights for those
bits (16+8+2 = 26).
Figure 11-2
16-bit status register
(2
7
)(2
6
)(2
5
)(2
4
)(2
3
)
(2
2
)
(2
1
)(2
0
)
(2
14
)
(2
13
)(2
12
)(2
11
)(2
10
)(2
9
)(2
8
)
16384
* By SCPI standard definition, B15 is not used. The bit is always 0.
Bit Position
Binary Value
Decimal
Weights
B7
B6
B5
B4
B3
B2
B1
B0
0/1
0/1
0/10/1 0/1 0/10/10/1
128
64
32
16
8
4
2
1
B15* B14 B13 B12 B11 B10 B9 B8
8192 4096 2048 1024 512 256
0
0/1 0/1
0/1 0/1 0/10/10/1
Bit Position
Binary Value
Decimal
Weights
B) Bits 8 through 15
A) Bits 0 through 7
