4-20 Range, Digits, Rate, Bandwidth, and Filter Model 2701 User’s Manual
Remote programming — filter
Filter commands
The filter commands are listed in Table 4-6. Additional information on these commands
follow the table.
NOTE Query commands are not included in Table 4-6. All commands for the SENSe
subsystem are provided in Table 15-5.
Table 4-6
Filter commands
Commands
1, 4
Description
5
Default
DCV filter commands
[SENSe[1]] Optional root command.
:VOLTage[:DC]:AVERage:TCONtrol <name> Select filter type; <name> = MOVing or
REPeat.
(Note 2)
:VOLTage[:DC]:AVERage:WINDow <NRf> Set filter window in %; <NRf> = 0 to 10. 0.1
:VOLTage[:DC]:AVERage:COUNt <n> [, clist] Specify filter count; <n> = 1 to 100. 10
:VOLTage[:DC]:AVERage:STATe <b> [, clist] Enable or disable the filter. (Note 3)
ACV filter commands
[SENSe[1]] Optional root command.
:VOLTage:AC:AVERage:TCONtrol <name> Select filter type; <name> = MOVing or
REPeat.
(Note 2)
:VOLTage:AC:AVERage:WINDow <NRf> Set filter window in %; <NRf> = 0 to 10. 0.1
:VOLTage:AC:AVERage:COUNt <n> [, clist] Specify filter count; <n> = 1 to 100. 10
:VOLTage:AC:AVERage:STATe <b> [, clist] Enable or disable the filter. (Note 3)
DCI filter commands
[SENSe[1]] Optional root command.
:CURRent[:DC]:AVERage:TCONtrol <name> Select filter type; <name> = MOVing or
REPeat.
(Note 2)
:CURRent[:DC]:AVERage:WINDow <NRf> Set filter window in %; <NRf> = 0 to 10. 0.1
:CURRent[:DC]:AVERage:COUNt <n>
[, clist]
Specify filter count; <n> = 1 to 100. 10
:CURRent[:DC]:AVERage:STATe <b> [, clist] Enable or disable the filter. (Note 3)
ACI filter commands
[SENSe[1]] Optional root command.
:CURRent:AC:AVERage:TCONtrol <name> Select filter type; <name> = MOVing or
REPeat.
(Note 2)
:CURRent:AC:AVERage:WINDow <NRf> Set filter window in %; <NRf> = 0 to 10. 0.1
:CURRent:AC:AVERage:COUNt <n> [, clist] Specify filter count; <n> = 1 to 100. 10
:CURRent:AC:AVERage:STATe <b> [, clist] Enable or disable the filter. (Note 3)
