13-2 SCPI Signal Oriented Commands Model 2701 User’s Manual

The signal oriented measurement commands are used to acquire readings. You can use

these high level instructions to control the measurement process. These commands are

summarized in Table 13-1.

NOTE When measurements are performed, the readings are fed to other enabled

operations. Appendix D explains “Data ﬂow (remote operation)” and provides

additional information on using FETCh?, READ?, and MEASure? to acquire

readings.

Table 13-1

Signal oriented measurement command summary

Command Description

CONFigure:<function> [<rang>], [<res>], [<clist>]

FETCh?

READ?

MEASure[:<function>]? [<rang>], [<res>], [<clist>]

Places the Model 2701 in a “one-shot” measurement

mode for the speciﬁed function.

Requests the latest reading.

Performs an ABORt, INITiate, and FETCh?.

Performs an ABORt, CONFigure:<function>, and

READ?. (See Note).

Channel list parameter:

<clist> = (@SCH)

where: S = Mainframe slot number (1 or 2)

CH = Switching module channel number (must be 2 digits)

Examples: (@101) = Slot 1, Channel 1

(@101, 203) = Slot 1, Channel 1 and Slot 2, Channel 3

(@101:110) = Slot 1, Channels 1 through 10

Note: Only one channel can be speciﬁed in the <clist> for the MEASure? command.
