Model 2701 User’s Manual Getting Started 1-25
Setting Factory *RST Set Diff
Limits Off Off
LO Limit 1 -1 -1
HI Limit 1 +1 +1
LO Limit 2 -2 -2
HI Limit 2 +2 +2
Line Synchronization Off Off
Math
mX+B Off Off
Scale Factor 1.0 1.0
Offset 0.0 0.0
Units “X” “X”
Percent Off Off
Reference 1.0 1.0
1/X (Reciprocal) Off Off
Monitor Off Off
Output
Beeper Never Never
Digital Output Off Off
Logic Sense High High
Pulse No (off) No (off)
Ratio Off Off
Resistance (Ω2 and Ω4)
Digits 6½ digits 6½ digits
Filter On Off ✓
Window 0.1% 0.1%
Count 10 10
Type Moving Repeat ✓
Offset compensation (OCOMP) Off Off
Range Auto Auto
Rate Slow (5 PLC) Slow (5 PLC)
Rel Off Off
Table 1-4 (continued)
Default settings
