G-12 KE2700 Instrument Driver Examples Model 2701 User’s Manual
LabVIEW examples
Table G-2 lists the LabVIEW examples and “Use Cases” that are provided with the
KE2700 Instrument Driver. LabVIEW examples are provided in the file: Examples.llb.
Use cases are provided in the file: Use Cases.llb. By default, these are installed in the
Program Files\National Instruments\LabView X\instr.lib\KE2700 directory.
In addition to the examples, numerous supporting VIs are included in the library file.
Table G-2
LabVIEW examples
Name
Manual
Reference Brief Description
Read multi-point
from channels
None Demonstrates configuring and reading multiple data points from
switching module channels.
Read multi-point
from front panel
None Demonstrates configuring and reading multiple data points from
the front panel input.
Read single point
from switching
module channel
None Demonstrates configuring and reading a single data point from
switching module channels.
Read single point
from front panel
None Demonstrates configuring and reading a single data point from the
front panel input.
Advance1 None Use Case 1 — 40-channel scan using 7708 module:
• 30 channels DCV (10V range).
• 10 channels type T thermocouple temperature.
• Measurement speed (rate) – 1 plc.
• Filter – Disabled (no filtering).
• Buffer – Store 160 reading strings. Buffer elements include
reading, channel #, and real time clock.
• Triggering – Timer scan; 40 channels every one minute.
• Data retrieval – SRQ when buffer ¼, ½, ¾, and full.
