Model 2701 User’s Manual SCPI Reference Tables 15-5
CALCulate3
:LIMit2 Path to control LIMIT 2 test: ✓
:UPPer Path to configure upper limit: ✓
[:DATA] <n>
[, <clist>]
Set upper limit (-4294967295 to
+4294967295).
2 ✓
[:DATA]? [<clist>] Query upper limit. ✓
:LOWer Path to configure lower limit: ✓
[:DATA] <n>
[, <clist>]
Set lower limit (-4294967295 to
+4294967295).
-2 ✓
[:DATA]? [<clist>] Query lower limit. ✓
:STATe <b>
[, <clist>]
Enable or disable limit test. OFF ✓
:STATe? [<clist>] Query state of limit test. ✓
:FAIL? Query test result (1 = failing). ✓
:CLEAR Path to clear events: ✓
[:IMMediate] Clear high and low events. ✓
:AUTO <b> Enable or disable auto-clear. ON ✓
:AUTO? Query auto-clear. ✓
Notes:
1. The :MMFactor and :MA1Factor commands perform the same operations.
2. The :MBFactor and :MA0Factor commands perform the same operations.
3. For mX+b units, <char> = one character; ‘A’ through ‘Z’, degrees symbol (‘°’), or ohms symbol (‘Ω’).
4. ON is the *RST default parameter and OFF is the SYSTem:PRESet default.
Table 15-2
DISPlay command summary
Command Description
Default
parameter Ref SCPI
DISPlay (see Note) Sec 1
[:WINDow[1]] ✓
:TEXT Path to control user text messages. ✓
:DATA <a> ASCII message “a” (up to 12 characters). (none) ✓
:DATA? Query text message. ✓
:STATe <b> Enable or disable message mode. OFF ✓
:STATe? Query text message state. ✓
:ENABle <b> Enable or disable the front panel display. ON ✓
:ENABle? Query state of the display. ✓
Note: *RST and SYSTem:PRESet have no effect on commands in this subsystem. The listed defaults are power-on defaults.
Table 15-1 (continued)
CALCulate command summary
Command Description
Default
parameter Ref SCPI
