4: Configuration Using the Web Manager
EDS4100 4 Port Device Server User Guide 43
Table 4-3. Line - Configuration Page
Line –
Configuration
Page Settings
Description
Status Select whether the selected EDS4100 serial port is enabled.
Choices are:
Enabled = the selected EDS4100 serial port is enabled.
Disabled = the selected EDS4100 serial port is disabled.
Interface Select the serial communication interface for serial lines 1 and 3.
This setting is not available for serial lines 2 and 4. Choices are:
RS232 = configures the serial line for RS232 communications.
(default)
RS485 Half-Duplex = configures the serial line for RS-485, half-
duplex (2-wire) communications.
RS485 Full-Duplex = configures the serial line for RS-422/485,
full-duplex (4-wire) communications.
Baud Rate Select the baud rate for the currently selected serial port.
Choices are:
300 baud to 230,000 baud. Default is 9600 baud.
Custom = lets you enter in the Custom text box a speed other
than those shown.
Parity Select the parity used by the currently selected serial port.
Choices are:
None (default)
Even
Odd
Data Bits Select the number of data bits used by the currently selected
serial port. Choices are:
7
8 (default)
Stop Bits Select the number of stop bits used by the currently selected
serial port. Choices are:
1 (default)
2
Flow Control Select the flow control method used by the currently selected
serial port. Choices are:
None(default)
Hardware
Software
