Mechanical installation
Standard devices in the power range 0.37 ... 11 kW
Mounting in "cold plate" technique
4
144
EDKVS9332X DE/EN/FR 8.0
4.1.4 Mounting in "cold plate" technique
The drive controllers can be mounted in ˜cold plate˜ technique, e.g. on collective coolers.
For this purpose, the drive controllers of type EVS93xx−Cxx must be used.
Mounting material required from the scope of supply:
Description Use
Quantity
EVS9321−Cx
EVS9322−Cx
EVS9323−Cx
EVS9324−Cx
EVS9325−Cx
EVS9326−Cx
Fixing bracket Controller fixing 2 2 2
Sheet metal screw
3.5 × 13 mm (DIN 7981)
Mounting the fixing bracket
to the controller
6 6 6
Requirements for collective coolers
The following points are important for safe and reliable operation of the controller:
ƒ Good thermal connection to the cooler
– The contact surface between the collective cooler and the controller must be at
least as large as the cooling plate of the controller.
– Plane contact surface, max. deviation 0.05 mm.
– When attaching the collective cooler to the controller, make sure to use all
specified screw connections.
ƒ Observe the thermal resistance R
th
given in the table. The values are valid for
controller operation under rated conditions.
9300 Cooling path
Power to be dissipated Heatsink − environment
Type P
v
[W] R
th
[K/W]
EVS9321−Cx 24 1.45
EVS9322−Cx 42 0.85
EVS9323−Cx 61 0.57
EVS9324−Cx 105 0.33
EVS9325−Cx 180 0.19
EVS9326−Cx 360 0.10
Ambient conditions
ƒ The rated data and the derating factors at increased temperature also apply to the
ambient temperature of the drive controllers.
ƒ Temperature at the cooling plate of the drive controller: max. 75 °C.
