Lenze 9300 Series Mounting Instructions

Electrical installation
Standard devices in the power range 0.37 ... 11 kW
Mains choke/mains filter assignment
5

167
EDKVS9332X DE/EN/FR 8.0
Installation to UL
Supply conditions
Range Description
Fuses l Only in accordance with UL 248
l System short−circuit current up to 5000 A
rms
: All classes are permissible
l System short−circuit current up to 50000 A
rms
: Only classes "CC", "J", "T" or "R" permissible
Cables l Only in accordance with UL
l The cable cross−sections specified in the following apply under the following conditions:
– Conductor temperature < 60 °C
– Ambient temperature < 40 °C
Observe all national and regional regulations!
9300 Rated fuse current Cable cross−section
Fuse L1, L2, L3, PE
Type [A] [AWG]
Operation without mains choke/mains filter
EVS9321−xx 6 18
EVS9322−xx 6 18
EVS9323−xx 10 16
EVS9325−xx 25 10
Operation with mains choke/mains filter
EVS9321−xx 6 18
EVS9322−xx 6 18
EVS9323−xx 10 16
EVS9324−xx 10 16
EVS9325−xx 25 10
EVS9326−xx 25 10
Max. connection cross−section of the terminal strip: AWG 12, with pin−end connector AWG 10
5.4.4 Mains choke/mains filter assignment
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVS9321−xx EZN3A2400H002 EZN3A2400H002 5 EZN3B2400H002 50
EVS9322−xx EZN3A1500H003 EZN3A1500H003 5 EZN3B1500H003 50
EVS9323−xx EZN3A0900H004 EZN3A0900H004 5 EZN3B0900H004 50
EVS9324−xx EZN3A0500H007 EZN3A0500H007 5 EZN3B0500H007 50
EVS9325−xx EZN3A0300H013 EZN3A0300H013 5 EZN3B0300H013 50
EVS9326−xx ELN3−0150H024−001 EZN3A0150H024 5 EZN3B0150H024 50

Lenze 9300 Series Specifications

General

Series	9300
Category	Controller
Manufacturer	Lenze
Protection Class	IP20
Communication	Ethernet, PROFIBUS
Communication Interfaces	Ethernet, PROFIBUS
Ambient Temperature	0°C to +45°C
Storage Temperature	-25°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	380-480V AC
Altitude	0 ... 2000 m above sea level, derating > 2000 m
