Lenze 9300 Series Mounting Instructions

Electrical installation
Standard devices in the power range 15 ... 30 kW
Mains choke/mains filter assignment
5

176
EDKVS9332X DE/EN/FR 8.0
5.5.4 Mains choke/mains filter assignment
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVS9327−xx ELN3−0088H035−001 EZN3A0110H030 25
E82ZN22334B230 10
E82ZZ15334B230
1)
10
E82ZN22334B230 50
EZN3B0110H030U
2)
50
E82ZZ15334B230
1)
50
EVS9328−xx ELN3−0075H045
EZN3A0080H042 25 E82ZN22334B230 10
E82ZN22334B230 50 EZN3B0080H042 50
EVS9329−xx ELN3−0055H055
EZN3A0055H060 25 E82ZN30334B230 10
E82ZN30334B230 50 EZN3B0055H060 50
1)
RFI filter
2)
Footprint filter

Lenze 9300 Series Specifications

General

Series	9300
Category	Controller
Manufacturer	Lenze
Protection Class	IP20
Communication	Ethernet, PROFIBUS
Communication Interfaces	Ethernet, PROFIBUS
Ambient Temperature	0°C to +45°C
Storage Temperature	-25°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	380-480V AC
Altitude	0 ... 2000 m above sea level, derating > 2000 m
