Lenze 9300 Series Mounting Instructions

Final works
Preparing the commissioning procedure
6

217
EDKVS9332X DE/EN/FR 8.0
6.2 Preparing the commissioning procedure
For commissioning with a keypad you require:
ƒ An EMZ9371BCkeypad
For commissioning with a PC you require:
ƒ A computer with a Windows® XP operating system
ƒ The Lenze PC software »Global Drive Control (GDC)«
ƒ A connection to the controller via an interface:
Controller Connection PC
Interface PC adapter Interface
Integrated system bus or
a CANopen EMF2175IB
communication module
System bus cable (is
enclosed with the
system bus
adapters)
EMF2173IB system bus adapter Parallel
EMF2177IBsystem bus adapter USB
EMF2102IBCV001 LECOM-A/B
communication module
Serial cable
EWL0020
EWL0021
For LECOM−B the following is
required:
l A standard RS232/RS485
converter
l A RS485 connection cable
Serial (RS232)
EMF2102IBCV003
LECOM−LIcommunication module
Optical fibre
EWZ0006
EWZ0007
Optical fibre adapter
EMF2125IB
EMF2126IB
Furthermore you require:
ƒ The system manual for the controller used
ƒ If required, the communication manual (KHB) for the network of the automation
platform
ƒ Mains voltage or 24 V voltage supply for the control electronics of the controller
Follow the instructions of the software and/or read the documentation.

Lenze 9300 Series Specifications

General

Series	9300
Category	Controller
Manufacturer	Lenze
Protection Class	IP20
Communication	Ethernet, PROFIBUS
Communication Interfaces	Ethernet, PROFIBUS
Ambient Temperature	0°C to +45°C
Storage Temperature	-25°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	380-480V AC
Altitude	0 ... 2000 m above sea level, derating > 2000 m
