Lenze 9300 Series Mounting Instructions

Electrical installation
Standard devices in the power range 55 ... 75 kW
Mains choke/mains filter assignment
5

193
EDKVS9332X DE/EN/FR 8.0
5.7.4 Mains choke/mains filter assignment
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVS9331−xx ELN3−0027H105
EZN3A0022H150 25 E82ZN75334B230 10
E82ZN75334B230 50 EZN3B0022H150 50
EVS9332−xx ELN3−0022H130
EZN3A0022H150 25 E82ZN75334B230 10
E82ZN75334B230 50 EZN3B0022H150 50

Lenze 9300 Series Specifications

General

Series	9300
Category	Controller
Manufacturer	Lenze
Protection Class	IP20
Communication	Ethernet, PROFIBUS
Communication Interfaces	Ethernet, PROFIBUS
Ambient Temperature	0°C to +45°C
Storage Temperature	-25°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	380-480V AC
Altitude	0 ... 2000 m above sea level, derating > 2000 m
