Electrical installation
Standard devices in the power range 0.37 ... 11 kW
Mains connection: Fuses and cable cross−sections
5
166
EDKVS9332X DE/EN/FR 8.0
5.4.3 Mains connection: Fuses and cable cross−sections
Installation in accordance with EN 60204−1
Supply conditions
Range Description
Fuses l Utilisation category: only gG/gL or gRL
Cables Laying systems B2 and C: Use of PVC−insulated copper cables, conductor temperature < 70 °C,
ambient temperature < 40 °C, no bundling of the cables or cores, three loaded cores. The data are
recommendations. Other dimensionings/laying systems are possible (e.g. in accordance with
VDE 0298−4).
RCCB l Controllers can cause a DC current in the PE conductor. If a residual current device (RCD) or a
fault current monitoring unit (RCM) is used for protection in the case of direct or indirect
contact, only one RCD/RCM of the following type can be used on the current supply side:
– Type B (universal−current sensitive) for connection to a three−phase system
– Type A (pulse−current sensitive) or type B (universal−current sensitive) for connection to a
1−phase system
Alternatively another protective measure can be used, like for instance isolation from the
environment by means of double or reinforced insulation, or isolation from the supply system
by using a transformer.
l Earth−leakage circuit breakers must only be installed between mains supply and controller.
Observe all national and regional regulations!
9300 Rated fuse current Cable cross−section FI
1)
Fuse Circuit−breaker Laying system L1, L2, L3, PE
B2 C
Type [A] [A] [mm
2
] [mm
2
] [mA]
Operation without mains choke/mains filter
EVS9321−xx 6 C6, B6
2)
1 1
300
EVS9322−xx 6 C6, B6
2)
1 1
EVS9323−xx 10 B10 1.5 1
EVS9325−xx 25 B20 4 2.5
Operation with mains choke/mains filter
EVS9321−xx 6 C6, B6
2)
1 1
300
EVS9322−xx 6 C6, B6
2)
1 1
EVS9323−xx 10 B10 1.5 1
EVS9324−xx 10 B10 1.5 1
EVS9325−xx 20 B16 2.5 2.5
EVS9326−xx 32 B25 ˘ 4
1)
Universal current−sensitive earth−leakage circuit breaker
2)
For short−time mains interruptions, use circuit breakers with tripping characteristic "C"
