Lenze 9300 Series Mounting Instructions

Electrical installation
Standard devices with a power of 45 kW
Mains choke/mains filter assignment
5

185
EDKVS9332X DE/EN/FR 8.0
5.6.4 Mains choke/mains filter assignment
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVS9330−xx ELN3−0038H085
EZN3A0030H110 25
EZN3B0030H110 50
EZN3A0030H110N001
3)
25
E82ZN55334B230 50
3)
For controllers with thermal separation

Lenze 9300 Series Specifications

General

Series	9300
Category	Controller
Manufacturer	Lenze
Protection Class	IP20
Communication	Ethernet, PROFIBUS
Communication Interfaces	Ethernet, PROFIBUS
Ambient Temperature	0°C to +45°C
Storage Temperature	-25°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	380-480V AC
Altitude	0 ... 2000 m above sea level, derating > 2000 m
