Lexmark XC4150 Service Manual

Symptoms
Base printer symptoms
Symptom Action
Printer has no power. See
“Dead machine service check” on page 262.
Control panel not functioning. See
“Control panel service check” on page 259.
False values for the front door appear on the
display.
See
“Interlock switch service check” on page 260.
NFC communications failure. See
“Mobile solutions module NFC service check” on page 264.
Toner out displays. See
“Toner meter cycle (TMC) card service check” on page 268.
Printer not communicating with host (USB). See
“USB service check” on page 269.
Printer not communicating with host
(network).
See
“Network service check” on page 265.
Paper jam in the output bin. See
“Sensor (output bin full) static jam service check” on page 93.
Control panel service check
Action Yes No
Step 1
Reset the printer.
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
Check the blue LED on the control panel.
Is the LED on?
Go to step 3. Go to step 4.
Step 3
Check the Ethernet and controller board LEDs on the control panel.
Are the LEDs on?
Go to step 4. Go to step 9.
Step 4
Check the ribbon cable connection on the control panel and
controller board.
Is the cable properly connected at both ends?
Go to step 6. Go to step 5.
Step 5
Reconnect the cable.
Does the problem remain?
Go to step 6. The problem is
solved.
7528
Diagnostic information
259

Lexmark XC4150 Specifications

General

Print technology	Laser
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum copy resolution	- DPI
Time to first copy (black, normal)	6.5 s
Time to first copy (color, normal)	7 s
Copy speed (black, normal quality, A4)	50 cpm
Scanner type	ADF scanner
Duplex scanning	Yes
Scan speed (black)	56 ppm
Duplex scan speed (black)	26 ppm
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Maximum internal memory	4096 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	53 dB
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	533.4 mm
Width	505.46 mm
Height	647.7 mm
