Lexmark XC4150 Service Manual

Diagnostic information
CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock and to prevent damage to the printer,
remove the power cord from the electrical outlet before you connect or disconnect any cable or
electronic card or assembly for personal safety and to prevent damage to the printer. Disconnect any
connections between the printer and computers or peripherals.
CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or
more trained personnel to lift it safely. Always use the hand holds on the sides of the printer. Make sure
that your fingers are not under the printer when you lift or set the printer down.
CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching.
Troubleshooting overview
Performing the initial troubleshooting check
• With the power cord unplugged from the electrical outlet, check if the cord is free from breakage, short
circuits, disconnected wires, or incorrect connections.
• Make sure that the printer is properly grounded.
• Make sure that the power supply line voltage is within 10% of the rated line voltage.
• Make sure that the printer is securely installed on a level surface in a well‑ventilated area.
• Make sure that the temperature and relative humidity are within the specifications. See “Temperature
information” on page 523.
• Avoid locations that:
– Generate ammonia gas
– Are exposed to direct sunlight
– Are near open flames
– Are dusty
• Make sure that the recommended paper for this printer is used.
• Do a test print with paper from a newly opened package, and then check the result.
Power‑on reset (POR) sequence
When you turn on the printer, it performs a POR sequence.
Check for the correct POR function of the printer by observing the following:
1 The initial boot screen appears.
2 The splash screen appears.
7528
Diagnostic information
35

Lexmark XC4150 Specifications

General

Print technology	Laser
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum copy resolution	- DPI
Time to first copy (black, normal)	6.5 s
Time to first copy (color, normal)	7 s
Copy speed (black, normal quality, A4)	50 cpm
Scanner type	ADF scanner
Duplex scanning	Yes
Scan speed (black)	56 ppm
Duplex scan speed (black)	26 ppm
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Maximum internal memory	4096 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	53 dB
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	533.4 mm
Width	505.46 mm
Height	647.7 mm
