Lexmark XC4150 Service Manual

Action Yes No
Step 3
Check the paper path for partially fed or jammed paper.
Is the paper path free of partially fed or jammed paper?
Go to step 5. Go to step 4.
Step 4
Remove the partially fed or jammed paper.
Does the problem remain?
Go to step 5. The problem is
solved.
Step 5
a Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Sensor tests
b Find the sensor (Fuser buckle).
Does the sensor status change while toggling the sensor?
Contact the next
level of support.
Go to step 6.
Step 6
Check the sensor cable for proper connection and damage, and
replace if necessary.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
a Check the sensor for damage, and replace if necessary.
b Perform a print job.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
202 paper jams
202 paper jam messages
Error code Description Action
202.12 Paper fed from tray 1 was detected earlier than
expected at the sensor (fuser exit).
See
“Sensor (fuser exit): Paper arrived too
early service check” on page 86.
202.13 Paper fed from tray 1 never arrived at the sensor
(fuser exit).
See
“Sensor (fuser exit): Paper failed to arrive
service check” on page 87.
202.14 Paper fed from tray 1 cleared the sensor (fuser
exit) earlier than expected.
See
“Sensor (fuser exit): Paper cleared too
early service check” on page 91.
202.15 Paper fed from tray 1 never cleared the sensor
(fuser exit).
See
“Sensor (fuser exit): Paper failed to clear
service check” on page 89.
202.22 Paper fed from tray 2 was detected earlier than
expected at the sensor (fuser exit).
See
“Sensor (fuser exit): Paper arrived too
early service check” on page 86.
202.23 Paper fed from tray 2 never arrived at the sensor
(fuser exit).
See
“Sensor (fuser exit): Paper failed to arrive
service check” on page 87.
7528
Diagnostic information
85

Lexmark XC4150 Specifications

General

Print technology	Laser
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum copy resolution	- DPI
Time to first copy (black, normal)	6.5 s
Time to first copy (color, normal)	7 s
Copy speed (black, normal quality, A4)	50 cpm
Scanner type	ADF scanner
Duplex scanning	Yes
Scan speed (black)	56 ppm
Duplex scan speed (black)	26 ppm
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Maximum internal memory	4096 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	53 dB
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	533.4 mm
Width	505.46 mm
Height	647.7 mm
