Lexmark XC4150 Service Manual

Action Yes No
Step 6
Perform the color alignment service check for all the colors.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Perform the auto alignment sensors service check.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Remove the printhead, and then check the printhead lenses for
contamination. See
“Printhead removal” on page 413.
Are the lenses contaminated?
Go to step 9. Go to step 10.
Step 9
Clean the lenses, and then reinstall the printhead.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
Replace the EP gear box. See
“EP gear box removal” on
page 356.
Does the problem remain?
Go to step 11. The problem is
solved.
Step 11
Replace the printhead. See
“Printhead removal” on page 413.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 12
Replace the controller board. See
“Controller board removal” on
page 409.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Horizontal colored lines or banding check
ABCDE
ABCDE
ABCDE
7528
Diagnostic information
43

Lexmark XC4150 Specifications

General

Print technology	Laser
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum copy resolution	- DPI
Time to first copy (black, normal)	6.5 s
Time to first copy (color, normal)	7 s
Copy speed (black, normal quality, A4)	50 cpm
Scanner type	ADF scanner
Duplex scanning	Yes
Scan speed (black)	56 ppm
Duplex scan speed (black)	26 ppm
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Maximum internal memory	4096 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	53 dB
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	533.4 mm
Width	505.46 mm
Height	647.7 mm
