Lexmark XC4150 Service Manual

Action Yes No
Step 6
Check the cable for damage, and replace if necessary.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Replace the control panel cable.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Replace the control panel. See
“Control panel removal” on
page 337.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 9
Disconnect the LVPS cable from the controller board, and then
measure the voltages of the red and orange wires.
Is the reading on the red wire +6.5 V, and the orange wire +25 V?
Go to step 12. Go to step 10.
Step 10
Replace the LVPS cable.
Does the problem remain?
Go to step 11. The problem is
solved.
Step 11
Replace the LVPS. See
“LVPS removal” on page 359.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 12
Replace the controller board. See
“Controller board removal” on
page 409.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Interlock switch service check
Action Yes No
Step 1
a Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Sensor tests
b Find the sensor (Door interlock).
Does the sensor status change while toggling the sensor?
The problem is
solved.
Go to step 2.
7528
Diagnostic information
260

Lexmark XC4150 Specifications

General

Print technology	Laser
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum copy resolution	- DPI
Time to first copy (black, normal)	6.5 s
Time to first copy (color, normal)	7 s
Copy speed (black, normal quality, A4)	50 cpm
Scanner type	ADF scanner
Duplex scanning	Yes
Scan speed (black)	56 ppm
Duplex scan speed (black)	26 ppm
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Maximum internal memory	4096 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	53 dB
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	533.4 mm
Width	505.46 mm
Height	647.7 mm
