Lexmark XC4150 Service Manual

Action Yes No
Step 6
a Reinstall, repair, or replace the TPS sled and wiper mechanism.
b Perform the auto alignment service check. See “Auto
alignment service check” on page 272.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Check the cable on the sensor (TPS) and on the JTPSAA1
connector on the controller board for proper connection, and
reseat if necessary.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
a Replace the sensor (TPS). See “Sensor (TPS) removal” on
page 379.
b Enter the Diagnostics menu, and then navigate to:
Printer setup > EP setup > Toner patch sensor adjust
c On the sensor gain characterization row, touch Start.
d On the sensor gain verification row, touch Start.
e On the sensor gain verification section of the test page, check
the average signal values of the patch number.
Are the values within the requirement?
The problem is
solved.
Contact the next
level of support.
Auto alignment service check
Pre‑check procedure
1
Enter the Diagnostics menu, and then navigate to:
Printer setup > EP setup > Toner patch sensor adjust > Clean sensing and laser optics
2 Allow the cleaning operation to run for three minutes.
3 Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Color alignment adjust
4 On the AA adjustment row, touch Start.
Note: This triggers the auto align routine which performs the color alignment error corrections.
The following lists the dierent auto align routine results:
• AA Result 1—Failed to complete
• AA Result 2—Normal data deficient
• AA Result 3—All OK, normal data within limits
• AA Result 4—Normal exceeds sense limits
• AA Result 5—Normal exceeds margin limits
• AA Result 6—All OK, normal corrections applied
7528
Diagnostic information
272

Lexmark XC4150 Specifications

General

Print technology	Laser
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum copy resolution	- DPI
Time to first copy (black, normal)	6.5 s
Time to first copy (color, normal)	7 s
Copy speed (black, normal quality, A4)	50 cpm
Scanner type	ADF scanner
Duplex scanning	Yes
Scan speed (black)	56 ppm
Duplex scan speed (black)	26 ppm
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Maximum internal memory	4096 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	53 dB
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Power consumption (average operating)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	533.4 mm
Width	505.46 mm
Height	647.7 mm
