Chapter 16 Connecting to Network
231
Connecting to
PC, Printer, and
Network
16.4.2
Transferring Image to FTP Server
Image transfer to an FTP server can be done with either of the following:
(1) Storing image to FTP server while being captured
(2) Transferring stored image to FTP server
Settings for storing image on an FTP server while being captured
If you want to store an image on an FTP server while the image is being captured, configure the following settings.
• Configure the FTP client function of DS-L3.
Enable [FTP CLIENT] in the [EXTERNAL SERVER] area of the [SETUP MENU: NETWORK] screen, and configure
[SERVER No], [IP ADDRESS], [USER ID], and [PASSWORD] settings. See “13.3.2 Configuring FTP Client”.
• Config
ure settings about FTP folder and file name.
Configure settings for automatic folder/file name creation in the [FTP SERVER DIR] and [FILE NAME] areas of the
[SETUP MENU: FILE] screen. See “13.4.1 (2) Configuring automatic folder creation in FTP server” and “13.4.2
Configuring File Naming Convention”.
• Config
ure the capture function.
Select [SAVE TO SERVER] in the [CAPTURE FUNCTION] area of the [SETUP MENU: ADDITIONAL] screen. See “13.5.2
Configuring Capture Function”.
Overwriting the file with the same name
On sending an image to an FTP server, no check is done to ensure no file with the same name exists. In order to avoid
overwriting of an image file, configure so that a file name contains date and time information.
You can use a serial number for file names to avoid this trouble. Note that the serial number is reset to “0001” when the
name of the storage folder or file is changed. A previously saved file may be overwritten and deleted.
(1) Storing image to FTP server while being captured
This system allows you to store an image to an FTP server while the system is capturing the image.
A live image can be saved as it is in the FTP server when you
capture the image on the touch panel LCD monitor.
Action taken during image capturing
By setting options in the [Capture Function] area, you
can save a live image on a recording medium or an FTP
server while being printed, or directly store it on the FTP
server without saving it on the recording medium.
Consecutive capture with interval timer
When saving images to an FTP server with consecutive
capture, the number of capturing times may be
decreased if more time is required for FTP transfer than
the shooting interval. Test this feature before using.
Printing Image by Capturing
FTP server
Capture an image.
To Next Page
