Chapter 16 Connecting to Network
233
Connecting to
PC, Printer, and
Network
16.5
Obtaining Images from the PC Using the FTP Command
You can obtain a live image of the DS-L3 by executing the FTP command from the PC.
Executing FTP command
Before executing the FTP command, be sure to consult the network administrator of your organization. Since unique
settings may be made in some organizations, executing the FTP command may cause a network error.
Perform operation on the command prompt screen to execute the FTP command from the PC.
1 Open Windows [ Command Prompt] and enter the IP address of DS-L3 to make a connection.
For an example of DS-L3 IP address of “192.168.10.2”:
• Example: FTP 192.168.10.2
2 Execute the Is command to search the “RAMIBOX” folder.
3 Execute the cd RAMIBOX command.
The following file names are displayed virtually.
• IMG**.bmp
• IMG***jpg
• IMG***tif
An image size value such as 2560 and 1280 is displayed in the “***” area.
The file update time at this time is “0:00”, but the Get command issuing time is set in the file that is actually obtained.
4 Execute the Get command to one file out of the files shown above to obtain the live image at the time.
In case of image acquisition failure
While PC and DS-L3 are connected with a USB cable and accesses are made frequently between them, image file
acquisition using the FTP command fails in some cases. In that case, stop access through the USB cable.
