Nikon Z 8 User Manual

D Computer USB P
ower Delivery
Before using a computer to supply power to the camera, check that the computer is equipped with
a Type C USB connector. Use an optional UC-E25 USB cable with Type C connectors at both ends to
connect the camera to the computer.
Depending on the model and product specifications, some computers will not supply current to
power the camera.
Tip: “Power Delivery” Versus “Charging”
The supply of power for camera operations is referred to as “power delivery”, while the term “charging”
is used when power is supplied only to charge the camera battery. The conditions under which the
power supplied by external devices is used to power the camera or charge the battery are shown
below.
Option selected for [USB power
delivery]
Power switch External power source used for
[ON]
On (standby timer active)
1
Power delivery
On (standby timer off) Charging
2
Off Charging
2
[OFF]
On (standby timer active)
1
—
On (standby timer off) Charging
2
Off Charging
2
Includes instances in which the power switch is in the “OFF” position but Bluetooth upload is in
progress or the memory card access lamp is lit.
EN‑EL15c and EN‑EL15b batteries inserted in the camera will charge when the camera is
connected to an optional EH‑7P charging AC adapter, EH‑8P AC adapter, or a computer (note
that connections to computers or the EH‑8P require a UC‑E25 USB cable, available separately).
755
USB Power Delivery
1
2

Nikon Z 8 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Sensor Resolution	45.7 MP
Image Processor	EXPEED 7
ISO Sensitivity	64-25600 (expandable to 32-102400)
Dimensions	144 x 118.5 x 83 mm
Weather Sealing	Yes
Sensor Size	35.9 x 23.9 mm
Viewfinder	3.69M-dot OLED electronic viewfinder
Monitor	3.2-inch tilting touchscreen LCD, 2.1M dots
Video Recording	8K UHD at 30p
Storage Media	CFexpress Type B
Battery	EN-EL15c
Weight	910 g
Autofocus System	493-point hybrid phase-detection/contrast AF
Continuous Shooting Speed	Up to 20 fps (RAW), Up to 30 fps (JPEG)
