Olympus RollerFORM User Manual

DMTA-20073-01EN, Rev. C, November 2015
Specifications 141
Figure 7-1 LEMO connector pinout diagram for EWIX1439 cable family
+5 V
PHB-1
PHA-1
+5 V
PHA-1
PHB-1
GND
Case Case
PHA-2
PHB-2
PHB-2
PHA-2
GND
Red
Brown
White/Brown
Black
White/Orange
White/Red
Instrument — 16-pin connector
RollerFORM
handle
Mini-Wheel encoder — 5-pin connector
Mini-Wheel
encoder
RollerFORM handle — 8-pin connector
Orange
White/Black
DIN 1
DIN 2
DIN 1
DIN 2
Red
Green
Blue
Black
NC
Case
Instrument
16-pin
connector
(weld side)
8-pin
connector
(weld side)
5-pin
connector
(weld side)
