Olympus RollerFORM User Manual

DMTA-20073-01EN, Rev. C, November 2015
Chapter 6 78
To remove the probe-axle from the acoustic wheel
1. Remove the bushing from the end of the probe-axle on the side of the acoustic
wheel that is opposite to the probe cable (see Figure 6-6 on page 78).
Figure 6-6 Removing the bushing from end of the probe-axle
Be careful not to damage the bearing seal underneath the C-clip with the pliers tips.
Bushing on the end of the probe-axle
