DMTA-20073-01EN, Rev. C, November 2015
Chapter 5
66
3. On the top of the laser casing, press the red On/Off button to activate the laser (see
Figure 5-3 on page 66).
Class 1 laser radiation. Avoid direct eye exposure to avoid injury.
Figure 5-3 The laser On/Off button on top of the laser casing
4. Make sure the guiding laser beam is properly aligned. For more information, see
“Adjusting the Angle of the Guiding Laser Beam” on page 136.
5. Position the RollerFORM in line with the first guide line drawn on the surface to
inspect, at the edge of the area to be inspected (see Figure 5-4 on page 67).
