DMTA-20073-01EN, Rev. C, November 2015
Chapter 6
88
Figure 6-15 Removing the acoustic wheel plain flange
3. Using mild soap and a soft cloth, thoroughly scrub the inner surface of the liquid
chamber clean, removing all deposits, particles, and viscous substance.
4. After you have finished cleaning the liquid chamber, rinse it thoroughly with
fresh water to remove any remaining deposits and particles, and then dry the tire
completely.
5. Install the flange by aligning the holes on the stainless steel ring to the holes on
the flange (see Figure 6-16 on page 89).
