Olympus RollerFORM User Manual

DMTA-20073-01EN, Rev. C, November 2015
RollerFORM Scanner Overview 19
Figure 1-2 The RollerFORM components
1.2 Acoustic Wheel
The RollerFORM’s liquid-filled acoustic wheel is composed of several components
that constitute the liquid chamber and ensure its watertightness (see Figure 1-3 on
page 20).
Probe angle adjustment
knob and mechanism
Liquid-filled
acoustic wheel
Middle wheel
height
adjustment knob
and locking
mechanism
Alternate
encoder holder
Laser guide
Handle
Indexer ClickerStart Acquisition button
Probe-axle
Probe cable
Laser retaining
screw
On/Off button (laser guide)
