2-14SectionRecipes
235
Symbol AllocationCS/CJ-series PCsAllocationCV-series PCsAllocationC-series PCs
TU --- --- --- ---
TC Area,
Timer Completion Flags
Not with
Host Link
C
TC Area,
Counter PVs
No
Counter Area,
Counter PVs
No
TC Area,
Counter PVs
No
CU --- --- --- ---
TC Area,
Counter Completion Flags
Not with
Host Link
W --- --- --- --- WR Area
Not with
Host Link
TK --- --- --- --- Task Flags
Not with
Host Link
D DM Area OK DM Area OK DM Area OK
E
EM Area
*2
,
current bank
OK
EM Area,
current bank
Not with
Host Link
EM Area,
current bank
Not with
Host Link
E0_ to
EC_
--- --- --- ---
EM Area,
EM banks 0 to C
Not with
Host Link
*1: LR 00000 to LR 00199 are converted to CIO 01000 to CIO 01199.
*2: The EM Area is supported only by the C200HX/HG/HE(-Z)E PCs.
Since the Auxiliary Area of the CVM1/CV-series PCs is allocated to system func-
tions, it cannot be used for purposes other than system use.
The range of each memory area differs according to the PC. Refer to Appendix D
PC Memory Maps on page 435.
When a DM Area or EM Area address is specified, add a bit number (00 to 15) to
the end of the word address.
Touch Switch Properties (General)
Touch switch Function (enable or disable as desired)
Page scroll touch
switches
Scroll up and down (to display records)
Scroll left and right (to display parameters)
Line scroll touch
switches
Scroll up and down (to display records)
Scroll left and right (to display parameters)
Read/write touch
switches
Read and write
For details of touch switch properties, refer to 2-7 Touch Switches (page 119).
2-14-5 Display Functions
Values are displayed in recipes according to the General settings.
For details on the method of display depending on the General settings, refer to
Common Attributes (page 227).
2-14-6 Input Functions
Enter values using numerical input and confirmation touch switches (control
code input keys) on the base screen or pop-up windows.
Read the contents of the consecutive words specified in the host using the Read
touch switch on the PT.
2-14-7 Output Functions
Write the specified record details to consecutive words specified on the host us-
ing the Write touch switch on the PT.
Input by User
Input from Host
Output to Host
