3-10 Display and Setting of Calendar Clock
The PT provides a function for displaying and setting the date and time. This sec-
tion describes the procedure for using the clock function.
Numeral Memory Table Entries Used by the Clock Function
Numeral memory table entries 247 to 255 are reserved for the display and set-
ting of the clock function.
Memory table entries 247 to 253 are for display and reading, and No. 254 and
No. 255 are for setting. (With the NT21, table entry numbers 254 and 255 are
reserved by the system.)
With the NT31/NT31C or NT631/NT631C, memory table entries 247 to 253
store the clock data that is updated according to the operation of the clock built
into the PT. The data in these memory table entries cannot be changed from the
host.
With the NT21, the clock data read from the words allocated in the host is stored
in table entry numbers 247 to 253.
Function
Numer-
al
memory
table
entry
Digit
position
Informa-
tion
Value Remarks
Display/
reading
247 Second 00 to 59
reading
only
248 Minute 00 to 59
only
249 Hour 00 to 23 24-hour system
250 Date 01 to 31
251 Month 01 to 12
252 Year 00 to 99
Last 2 digits of the
year
253
Day of
week
00 to 06 See below.
Setting
only
254
Second 00 to 59
only
(NT31/
Date
Hour
Minute
Second
Minute 00 to 59
(NT31/
NT31C
or
Hour
Second
Hour 00 to 23 24-hour system
or
NT631/
NT631C)
Date 01 to 31
NT631C
)
(Re-
ser ed
255
Month 01 to 12
served
by sys-
tem for
Vacant
Day of
week
Year
Month
Year 00 to 99
Last 2 digits of the
year
tem
for
NT21.)
week
Day of
week
00 to 06
Vacant 00
The correspondence between the value and day of week is shown below.
Day of week Sun Mon Tue Wed Thu Fri Sat
Value 00 01 02 03 04 05 06
Example of setting for the NT31/NT31C or NT631/NT631C: September 28th,
’01 (Fri.), 14 H 53 M 30 S
254
255
028
1
45 33
00050109
