4-3SectionCommands/Responses
384
00 to FF
H
In the case of character string memory table entries allocated
words in the host, specify the registered number of words multi-
plied by 2, and in the case of character string memory table en-
tries not allocated words in the host, specify the data for 40
characters.
s
1
, s
2
: Checksum (2 hexadecimal digits)
When m is 0, omit this setting.
Reference: The maximum number that can be specified for character string memory table
entries depends on the setting for numbers of character string table entries
(256/1000/2000) made at the Support Tool. However, it is not possible to write to
character string memory table entries of numbers higher than No.500 since they
are used only as a reading area.
Response
Only if Yes is set for the Response memory switch, the response indicated below
is returned on normal completion.
Format
1B 57
[ESC] [CR]W
3530 32 0D53
S
30
0 0 s1 s2
s
1
, s
2
: Checksum (2 hexadecimal digits)
This is always added (fixed as 25H).
Writes specified data to the specified character string memory table entries.
4-3-10 Bit Memory Table Write Command (Sent from Host to PT)
Command
Format
Data of 16 tables
Data of 16 tables
m
1B 57
[ESC] W
t3 t4
42
Bt1 (l1) (l2)t2
2C
0D
d11 d14
,
dn1 dn4
(s1) (s2) [CR]
* ** * * * * * * * * * * * * *
* * * * * * * * * * * *
m: Checksum present/absent (1 BCD digit)
0: Absent
1: Present
8: Absent (effective only when 1 table entry written)
9: Present (effective only when 1 table entry written)
t
1
to t
4
: First bit memory table entry number written to (4 BCD digits)
0000 to 0999
l
1
, l
2
: Number of written table entries (2 BCD digits)
00: 100 table entries
01 to 99: 1 to 99 table entries
When m is 8 or 9, omit this setting.
d1
1
to d1
4
, ..., dn
1
to dn
4
:
Contents of the written bit memory table entries (4 hexadecimal
digits, × n)
0000 to FFFF
H
The contents of bit memory table entries are represented as 1
bit data (OFF=0, ON=1) and 16 entries of bit memory table are
Function
To Next Page
