Appendix ASpecifications
434
Item Specifications
Screen print function
(NT31/NT31C and
NT631/NT631C only)
Functions: - Prints a hard copy of the screen display
- Prints display/alarm histories
Setting: Set the printing protocol (Print Controller) and printing type (Print
Method) in the memory switch menu.
ESC/P, Color: Color printing conforming to ESC/P 24-J83C
PC-PR201H, Color: Color printing conforming to PC-PR201PL
ESC/P, Tone: Monochrome printing in 8 grayscale levels,
conforming to ESC/P 24-J82
PC-PR201H, Tone: Monochrome printing in 8 grayscale levels,
conforming to PC-PR201PL
PCL 5, Tone: Monochrome printing in 8 grayscale levels,
conforming to PCL 5
However, the NT31 and NT631 support monochrome printing only.
Calendar and clock function - For the NT31/NT31C and NT631/NT631C, displays the current time in accordance
with the built-in clock
- For the NT21, clock data is read from the host.
- Displayed and set with Calendar Check in the MAINTENANCE MODE menu.
(Setting is not possible for the NT21.)
Programming Console function Executes functions equivalent to those of a Programming Console (model
C200H-PRO27-E) with C-series CPM1, CPM1A, CPM2A, CPM2C, CQM1 (-EV1
only), CQM1H, C200HX/HG/HE(-Z)E, and SRM1 (C02-V2 only).
Executes functions as a Programming Console for CS/CJ-series PCs.
Device Monitor function
(NT31/NT31C and
NT631/NT631C only)
The Device Monitor function can be used to change the PC’s operating mode,
read/change words in the PC’s data areas, and display the PC’s error log.
Compatible PCs include the CPM1, CPM1A, CPM2A, CPM2C, CQM1 (-EV1 only),
CQM1H, C200HX/HG/HE(-Z)E, SRM1, and CS/CJ-series PCs.
Mathematical function Up to 256 mathematical formulas can be registered along with the screen data. The
mathematical function reads the required data from numeral memory table entries or
host words, executes the registered calculations, and writes the results.
Arithmetic operators, logic operators, bit operators, and comparative operators can
be used.
Transmission
functions
System program
transmission
Downloads the system program from the system installer
Downloads/Upload the system program with a Memory Unit.
Screen data
transmission
- Function for downloading screen data to and uploading screen data from the
Support Tool
- Function for transmitting screen data to and from the Memory Unit.
Recipe table
transmission
Function for downloading/uploading recipe tables (i.e., all recipe data) from/to the
Support Tool.
History data
uploading
Function for uploading display/alarm history data from PT.
To Next Page
